Chapter 5: Working with Line Cards
58
Displaying Remote Module Status and Configuration Information
The AT-S70 management software provides comprehensive status
information about the operation of a remote module and its components.
Note
Allied Telesis Proprietary Remote Management – This feature is
only supported on the AT-CM Series line cards such as the
AT-CM202, and AT-CM212, and not the AT-CV Series line cards
such as the AT-CV10x and AT-CV1KSS. In order for Remote
Module Status and Configuration to work, the OAM Visible Mode
(operating mode) must be turned ON. This feature uses and extends
the IEEE 802.3 ah (OAM) protocol standard.
To view remote module status information, perform the following
procedure:
1. From the Main Menu, select Remote Module Status and
Configuration.
