AT-S70 Management Software User’s Guide
81
Figure 28. UART Configuration Menu
6. From the UART Configuration Menu, select one of the following
configurations:
UART Local Console Mode
Sets the UART configuration to communicate with other computers via
the local console mode. This is the default setting.
UART Back Plane Mode
Sets the UART configuration to communicate with the computers via
the backplane mode.
If you change the operational mode of the line card, the following
prompt is displayed:
Warning: Changing the Operation Mode will reset the line
card.
Change Operation Mode now? (Yes or No):
7. Type Y to accept the changes to the UART configuration, or type N to
cancel the changes.
Note
The default UART factory setting for the AT-CM70S line card is
“Local Console” which is good when the card installed in the
AT-CV1200 chassis.
When the AT-CM70S line card is first used in an AT-CV5000
chassis, you must change the UART setting to “UART Back Plane
Mode.” This setting is stored in non-volatile memory, and is effective
the next time the card boots up in an AT-CV5000 chassis.
8. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 10
on page 46.
9. From the System Configuration Menu, select Save Configuration
File.
