AT-S70 Management Software User’s Guide
95
The Diagnostics Menu is displayed, as shown in Figure 38.
Figure 38. Diagnostics Menu
3. From the Diagnostics Menu, select Chassis Diagnostics.
The AT-S70 management software runs the diagnostics on the
chassis and displays the results in the Chassis Diagnostics menu. The
example in Figure 39 shows an AT-CV5000 chassis.
Figure 39. Chassis Diagnostics Menu
Diagnostics Menu
Converteon
Chassis Diagnostics
Line Card Image Version
Line Card Information
SFP Information
Return to Administration Menu...
Chassis Diagnostics Menu
Converteon
Serial Number:
MAC Address 00:0C:46:98:22:5f
CONVERTEON Chassis: CV-5000 Chassis Revision
Running 0 days, 1 hours, 10 minutes, 9 seconds
Current Time: 00/00/00 01:10:47
Diagnostic Results:
Flash PROM Good
Serial Interface Good
RPSA Good
Temperature:
25
C
3.3V Power:
3.2 V
5V Power:
4.9 V
12V Power: 0.0 V
Fan Status:
Good
Fan1 Speed:
3924 RPM
Fan2 Speed:
3994 RPM
RPSB Not
Present
Temperature:
25
C
3.3V Power:
0 V
5V Power:
0 V
12V Power: 0.0 V
Fan Status:
Not Present
Fan1 Speed:
Off
Fan2 Speed:
3Off
Hit any key to continue ...
