AT-S70 Management Software User’s Guide
87
The Port Management Menu is displayed, as shown in Figure 33.
Figure 33. Port Management Menu for the AT-CM2K0S
5. From the Port Management Menu, select Port Configuration.
The Port Configuration Menu for the SFP port is shown in Figure 34.
Figure 34. Port Configuration Menu for the AT-CM2K0S
Note
The Port Enable and Port Disable options are described in “Enabling
and Disabling the Ports on a Line Card” on page 61.
6. From the Port Management Menu, select Port Statistics.
Port Management Menu
Module 14 - Port A
Port Configuration
Return to Module Configuration Menu...
Port Configuration Menu
Converteon
Module 14 - Port A
> Port Enable
Port Disable
Ingress_Rate_Limit
Egress_Rate_Limit
Port Statistics
Return to Port Management Menu ...
