Chapter 8: Operations, Administration, and Maintenance (OAM)
126
5. Press .
The Port Management Menu is displayed, as shown in Figure 48 on
page 116.
6. From the Port Management Menu, select OAM Configurations.
The OAM Configuration Menu is displayed, as shown in Figure 49 on
page 117.
7. From the OAM Configuration Menu, select the Show Remote OAM
Information Menu.
The Show Remote OAM Information Menu is displayed, shown in
Figure 52.
Figure 52. Show Remote OAM Information Menu
Displaying OAM
Statistics
To display the OAM statistics, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 46 on page 115.
2. Select the line card whose OAM statistics you want to display.
Show Remote OAM Information
Module = 5, Port = 1
MAC Address 00:0c:46:9a:21:c9 Mux State Forward
Parser State Forward Local Discovering Yes
Local Stable No Remote Discovering No
Remote Stable No Critical Event No
Dying Gasp No Link Fault No
OAM Version 0x01 Config Revision 0x0003
Vendor Info 0x00160001 Vendor OUI 00-30-84
Mode Active Max OAMPDU Size 1518
Loopback Support Yes Event Support No
Variable Support Yes Unidirect Support Yes
Return to OAM Configurations ...
