Chapter 5: Working with Line Cards
90
Displaying the
Port Ingress and
Egress Rate
Limits
To display the ingress and/or egress rates for a port on an AT-CM2K0S
line card, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the AT-CM2K0S line card whose information you want to
change.
3. Press .
The Module Configuration Menu is displayed, as shown in Figure 31
on page 85.
4. Select a port and press .
The Port Management Menu is displayed, as shown in Figure 33 on
page 87.
5. From the Port Management Menu, select Port Configuration.
The Port Configuration Menu for the SFP port is shown in Figure 34 on
page 87.
6. From the Port Management Menu, select Ingress Rate Limit or
Egress Rate Limit.
Note
The process for setting the ingress or egress rate limit is virtually the
same, except for the selection of ingress or egress. Therefore, the
figures in the rest of this procedure illustrate setting the ingress rate
limit as an example of how to do both.
The Port Ingress Rate Menu is displayed, as shown in Figure 36
7. From the Ingress Rate Limit Menu, select Show Ingress Rate Limit.
A message such as the following provides the current setting for the
ingress rate limit:
The current Ingress Rate Limit is
