Chapter 5: Working with Line Cards
64
Note
The rate limit feature on an AT-CM2K0S line card differs from the
feature described below. To configure the port rate limits on an
AT-CM2K0S line card, refer to “Setting the Port Ingress and Egress
Rate Limits” on page 88.
To configure the ingress/egress rate limit on a line card, perform the
following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the line card whose ingress/egress rate limit you want to set.
3. Press .
The Module Configuration Menu is displayed, as shown in Figure 13
on page 55.
4. Select the port that you want to configure.
5. Press .
The Port Management Menu is displayed, as shown in Figure 18 on
page 62.
6. From the Port Management Menu, select Port Configurations.
The Port Configuration Menu is displayed, as shown in Figure 18 on
page 62.
7. From the Port Configuration Menu, select Ingress_Rate_Limit or
Egress_Rate_Limit.
