Chapter 5: Working with Line Cards
84
3. Press .
The CPM switch over menu is displayed, as shown in Figure 30.
Figure 30. CPM Switchover Menu
4. Choose Yes to start the switchover process or choose No to cancel.
Resetting the
AT-CV5M01
Management
Card
To reset the AT-CV5M01Management Card and restart the AT-S70
management software, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the management card.
3. Press .
The Module Configuration Menu is displayed, as shown in Figure 29
on page 82.
4. From the Module Configuration Menu, select Reset CPM and Restart
System Software.
Note
This procedure resets only the AT-CV5M01Management Card, and
does not reset the line cards and/or the module installed in the
expansion slot at the rear of the chassis.
Another way to reset the AT-CV5M01Management Card is to press
the recessed CPU RESET button on the front of the management
card, as described in the AT-CV5000 Chassis Installation Guide.
Converteon
Do CPM switch over ? (Yes or No):
Yes
> No
Return to Administration Menu ...
