Chapter 5: Working with Line Cards
62
6. From the Port Management Menu, select Port Configurations.
The Port Configuration Menu is displayed, as shown in Figure 18.
Figure 18. Port Configuration Menu
7. Select Port Enable to enable the port or Port Disable to disable the
port. The default is enabled.
When the port is disabled, it no longer forwards packets. You might
want to disable a port if a problem occurs with the end node or with the
cable connected to the port. After the problem is fixed, you can enable
the port again to resume normal operation. You can also disable an
unused port to secure it from unauthorized connections.
8. From the Main Menu, select System Configuration.
The System Configuration Menu is displayed, as shown in Figure 10
on page 46.
9. From the System Configuration Menu, select Save Configuration
File.
Changing the
Line Card Port
Duplex Mode
To change the duplex mode of a port on a line card, perform the following
procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu is displayed, as shown in
Figure 12 on page 53.
2. Select the line card.
3. Press .
Port Configuration Menu
Converteon
Module 4 - Port A
> Port Enable
Port Disable
> Auto negotiate
Full
Half
Ingress_Rate_Limit
Egress_Rate_Limit
Return to Module Management Menu...
