AT-S70 Management Software User’s Guide
105
Working with the Event Log
This section contains the following procedures:
ˆ “Displaying the Event Log,” next
ˆ “Clearing the Event Log” on page 107
Displaying the
Event Log
To display the events in the event log, perform the following procedure:
1. From the Main Menu, select Administration.
The Administration Menu is displayed, as shown in Figure 6 on page
38.
2. From the Administration Menu, select Event Log.
The Event Log Menu window is displayed, as shown in Figure 44.
Figure 44. Event Log Menu
3. From the Event Log Menu, select Display Event Log.
Event Log Menu
Converteon
Display Event Log
Clear Event Log
Return to Administration Menu ...
