Publication 1757-IN040B-EN-P - March 2002
3-18 ProcessLogix Server Installation Procedures
4. In the Configure Drivers dialog box, you should see AB_PCIC-1
listed in the Configured Drivers list with the status Running. If
the AB_PCIC-1 driver status is not Running, call Rockwell
Automation Technical Support. Refer to Rockwell Automation
Technical Support in the Preface.
5. Click Close to close the Configure Drivers dialog box.
6. Close RSLinx.
7. Restart the PC.
Configuring RSLinx Drivers
for Ethernet Supervisory
Network
1. Verify the settings of the Ethernet Network Interface card to be
used to communicate with the controller.
IMPORTANT
Whenever the 1784-PCIC driver has been updated or
the Network Address is changed, the 1784-PCIC
driver must be stopped and restarted to complete the
change. You must power down the PC.
IMPORTANT
If you are installing ProcessLogix software on a
redundant Server pair:
1. Return to the beginning of Configuring RSLinx
Drivers for ControlNet Supervisory Network on
page 3-13 and repeat for SERVERB.
2. Once you have configured RSLinx drivers on
both SERVERA and SERVERB, continue with
Completing the ProcessLogix R400.0 Setup on a
Redundant Server Pair on page 6-1.
If you are installing ProcessLogix R400.0 software on
a Non-redundant server, continue with Completing
the ProcessLogix R400.0 Install on a Non-Redundant
Server on page 3-20.
IMPORTANT
If you are using ControlNet for your Supervisory
Network, skip this section.
Refer to Configuring RSLinx Drivers for ControlNet
Supervisory Network on page 3-13.
