Publication 1757-IN040B-EN-P - March 2002

5-18 ProcessLogix Client Installation and Upgrade Procedures

Installing ProcessLogix
R400.0 Client Software

Follow the steps in the section for installing the ProcessLogix R400.0
Client software.

Use the following procedure to install these ProcessLogix client
software components in succession.

Knowledge Builder

Engineering Tools (Engineering Workstation only)

Client/Server (Display Builder, Station, and Server)

1. Logon to the system as ps_user.

2. Close all running applications.

3. Insert the ProcessLogix R400.0 Software CD 1 into the CD-ROM

drive.

4. Click Start

Run.

5. Key in this path location in the Open entry field or use Browse

to navigate to the msxml3mm.exe file on the CD and click
Open.

>D:(or your CD-ROM drive letter)\XML3\msxml3mm.exe<

6. Click OK to launch the MSXML 3.0 setup application.

7. Click Yes to accept the license agreement.

8. Browse to C:\winnt\system32 and click OK.

9. Click Start

Run.

10. Key in this path location in the Open entry field or use Browse

to navigate to the setup.exe file on the CD.

>D:(or your CD-ROM drive letter)\SETUP.EXE<

IMPORTANT

If you plan to use Microsoft Excel Data Exchange,
you must install Microsoft Excel 2000 prior to starting
this procedure.

IMPORTANT

Be sure to logon as ps_user. If you don’t have a user
ps_user account, you must create one at this time.
Refer to Creating the ProcessLogix User Accounts on
page 2-26
.
