Restoring the data, Restoring the data -26 – Rockwell Automation 1757-SWKIT4000 ProcessLogix R400.0 Installation and Upgrade Guide User Manual
Page 200

Publication 1757-IN040B-EN-P - March 2002
8-26 Supplementary Procedures
Restoring the Data
Follow the steps below to import the data back into the Engineering
Repository Database.
1. Logon to the system as ps_user.
2. Select Start
⇒
Programs
⇒
ProcessLogix Engineering Tools
⇒
Control Builder.
3. In the Login dialog box, make these entries:
a. Key in >mngr< as the default User Name.
b. Key in >mngr1< as the default Password.
c. Key in the name of the appropriate Server node in the Server
Name field.
4. Click OK.
5. Click File
⇒
Import.
6. Click Browse and select the directory created in Step 2, Saving
Important Data on page 8-17.
7. Click Select All.
Depending on the size of your database, this may take several
minutes.
8. Click Import.
Depending on the size of your database, this step may take
several minutes to several hours.
9. When completed, close the Import Window.
At this point, each controller must be reloaded on the system.
10. Close Control Builder.
ATTENTION
!
If you are using this procedure for renaming and
setting redundant servers, finish setting up
redundancy before performing this step to restore
the Engineering Repository Database. (ERDB)
