Publication 1757-IN040B-EN-P - March 2002

ProcessLogix Client Installation and Upgrade Procedures 5-19

11. Click OK to launch the software setup application.

12. Select the Engineering Workstation or Operator Workstation

option and click Next.

13. At the Product Selection Completed window, click Continue.

14. The ProcessLogix R400.0 Software CD 1 ejects.

Installing Knowledge Builder

1. Insert the ProcessLogix R400.0 Knowledge Builder CD into the

CD-ROM drive and click Yes.

2. At the Welcome window, click Next.

3. Click the I accept the terms option and click Next.

4. Click the desired install type and click Next.

Full

Installs all components of the version selected
Required on all ProcessLogix systems

CD

This installs the Client side components on your
system.
You will be required to have the KB CD inserted
every time you run Knowledge Builder.

5. At the Ready to Install window, click Install.

6. At the Install Complete window, click Finish.

7. The Knowledge Builder CD ejects.

8. Insert the ProcessLogix R400.0 Software CD 2 into the CD-ROM

drive and click Yes.

ATTENTION

!

Clicking No will abort the entire installation.
