3-14 ProcessLogix Server Installation Procedures
3. Click the 1784-PCIC(S) for ControlNet devices selection in the
Available Drivers list box and click Add New to call up the Add
New RSLinx Driver dialog box.
4. Click OK to accept the default name AB_PCIC-1 for the driver.
5. In the Configure 1784-PCIC window, enter the following:
a. Serial Number(hex): This value is read from the PCIC card
and does not change.
b. Network Address(dec): Change the default of 99 to:
•
Non-redundant Server 24
•
Redundant Server A 24
•
Redundant Server B 23
6. Click OK to close the dialog box and start the PCIC driver.
7. In the Configure Drivers dialog box, you should see AB_PCIC-1
listed in the Configured Drivers list with the status Running. If
the AB_PCIC-1 driver status is not Running, call Rockwell
Automation Technical Support. Refer to Rockwell Automation
Technical Support in the Preface.
8. Click Close to close the Configure Drivers dialog box.
9. Close RSLinx.
IMPORTANT The driver name MUST be AB_PCIC-1
