Publication 1757-IN040B-EN-P - March 2002

Additional Redundant Server Procedures 6-3

Use the following format to make your separate line entries into
this file.

Where:

is:

IP Address

the assigned internet address with no leading zeros. For example, a
typical address could be >192.168.0.1<.

Computer Name

a base name of up to 13 characters, which must be the same for each
ProcessLogix Server in the system.

In a redundant Server system, you must append a letter to the
base name to identify the PC’s function in the system architecture
with the letters a and b for the Primary and Secondary Servers,
respectively.

EXAMPLE

For example, if you have a redundant Server
system and you assign a base name of PLX1, the
Computer Name for the Primary Server and
Secondary Engineering Repository Database
(ERDB) would be >PLX1A<, the Secondary Server
and Primary ERDB would be >PLX1B<.

Computer Name0

the computer name appended with a 0 to show its association with
the first Ethernet adapter card.

Computer Name1

the computer name appended with a 1 to show its association with
the second Ethernet adapter card (in a dual Local Area Network (LAN)
system).

EXAMPLE

For example, if you have a redundant Server
system with a dual LAN and a base computer
name of >PLX1<, the Computer Names would be
>PLX1A0<, >PLX1B0<, and >PLX1A1<,
>PLX1B1< for their respective addresses. If you
have a single LAN system, you only need to
append the Computer Name with a “0”.

Comment

any additional descriptive data you want to include for a given
Computer Name.

You must begin each entry with the number symbol >#<.

An example of a Host file with additional Host name entries and
comments is shown above for reference.

The Hosts file includes a default IP address of >127.0.0.1< for a
localhost. Do not delete this default entry from the Hosts file.
