Publication 1757-IN040B-EN-P - March 2002

8-28 Supplementary Procedures

2. Double-click the System icon.

3. On the Network Identification tab, click Properties.

4. Key in the desired computer name in the Computer name entry

field.

5. Click OK to initiate the change.

6. At the You must reboot prompt, click OK.

7. Click OK to Close the System Properties window.

8. Click Yes to restart the computer.

Procedure for Configuring a ProcessLogix Client

Changing Hosts files entries

Refer to Changing Hosts File Entries on page 6-1 to be certain that the
Hosts file on a ProcessLogix Client lists applicable Server names and
IP addresses.

Setting Up a ProcessLogix Client with a Non-redundant Server

If a ProcessLogix Client is networked to a non-redundant Server, refer
to Setting Up a ProcessLogix Client With a Non-redundant Server on
page 1-86. Use t
his procedure to confirm that any client reference the
correct non-redundant server or computer name or IP address.

Setting up a ProcessLogix Client with Redundant Servers

If ProcessLogix Client is networked to redundant Servers, refer
to Setting Up a ProcessLogix Client With Redundant Servers on
page 1-88.

Adding 1757-PLX52
Controller Redundancy to
R400.0 Non-Redundant
1757-PLX52 Controller
Configurations

ATTENTION

!

Be certain that your process is off control before you
begin any upgrade procedure. This means the
1757-PLX52 should be in the Idle state.
