7-6 Firmware Maintenance Procedures
ControlNet PCI
Interface card 1784-PCIC 3.5 \1784-PCIC\3_5_33 1784pcic_3_5.nvs
ControlNet to
Fieldbus Linking
Device 1757-CN2FF 1.2 \1757-CN2FF cn2ff.nvs
FOUNDATION
Fieldbus Interface
Module 1757-FIM PS400.0-19.3 \1757-FIM FimBoot.nvs
Fimrex.nvs
PROFIBUS
Interface Module SST-PFBCLX 2.1 N/A N/A
Ethernet TCPIP
Communication
Interface Card 1756-ENET/A 1.18 \ENET\1756-ENET-A 99236106.nvs
Pulse Input Module 1757-PIM 1.09 \IOM\1757-PIM\1_9 pim.nvs
Analog I/O
Modules 1756-IF6I/A 1.9 \IOM\Analog\1756_analog\1_9 99207408.nvs
1756-IF16/A 1.5 \IOM\Analog\1756_IF16\1_5 99223504.nvs
1756-IR6I/A 1.9 \IOM\Analog\1756_analog\1_9 99207408.nvs
1756-IT6I/A 1.9 \IOM\Analog\1756_analog\1_9 99207408.nvs
1756-OF6CI/A 1.9 \IOM\Analog\1756_analog\1_9 99207408.nvs
1756-OF6VI/A 1.9 \IOM\Analog\1756_analog\1_9 99207408.nvs
1756-OF8/A 1.5 \IOM\Analog\1756_OF8\1_5 99223704.nvs
Digital I/O
Modules 1756-IA16/A 2.4 IOM\Digital\1756-IA16\2_4 99213204.nvs
1756-IB16/A 2.4 IOM\Digital\1756-IB16\2_4 99212904.nvs
1756-IB32/A 2.6 IOM\Digital\1756-IB32\2_6 99207106.nvs
1756-IB16/A 2.4 IOM\Digital\1756-IB16\2_4 99212904.nvs
1756-IB16I/AI
(ASIC ver. 2.1)
1.7 IOM\Digital\1756-IB16I\1_7 99205106.nvs
(ASIC ver. 2.2) 2.1 IOM\Digital\1756-IB16I\2_1 99218601.nvs
1756-IA16I/A
(ASIC ver. 2.1)
1.7 IOM\Digital\1756-IA16I\1_7 99205306.nvs
(ASIC ver. 2.2) 2.1 IOM\Digital\1756-IA16I\2_1 99218401.nvs
1756-IM16I/A
(ASIC ver. 2.1)
1.7 IOM\Digital\1756-IM16I\1_7 9920406.nvs
(ASIC ver. 2.2) 2.1 IOM\Digital\1756-IM16I\2_1 99219801.nvs
Table 7.A Hardware component firmware revision level reference for R400.0
Component
Name Model Number Revision
Level for
R400.0 Directory File
