Publication 1757-IN040B-EN-P - March 2002

Firmware Maintenance Procedures 7-11

11. Wait for the load to complete and the 1757-PLX52, TC-MUX021,

or 1757-FIM module to reboot to its ALIVE status as shown in
the module LED display. The Status field in the lower portion of
the Network Tools window tracks the load progress.

12. Click OK to acknowledge the load completion with no errors.

13. Confirm that the LED display on the 1757-PLX52 or TC-MUX021

module shows ALIVE.

Loading Personality Image

1. With the 1757-PLX52, TC-MUX021, or 1757-FIM module in its

ALIVE state, click the 1757-PLX52, TC-MUX021, or 1757-FIM
module in the Detail pane.

2. Click Firmware

to initiate the firmware update.

3. Click Yes to acknowledge the Warning prompt.

4. To load the personality image to a 1757-PLX52, locate the

cee50.pcm personality (rex) file. See Table 7.A on page 7-5.

5. To load the personality image to a TC-MUX021, locate the

simrex.pcm personality (rex) file. See Table 7.A on page 7-5.

TIP

You should load the cee5.pcm file for CEE-5ms.
