Publication 1757-IN040B-EN-P - March 2002
ProcessLogix Server Installation Procedures 3-13
9. Restart the PC.
Configuring RSLinx Drivers
for ControlNet Supervisory
Network Use the following procedure to configure the ControlNet PCIC drivers
for RSLinx.
1. Click Start
⇒
Programs
⇒
Rockwell Software
⇒
RSLinx
⇒
RSLinx to
call up the Rockwell Software RSLinx window.
2. Click Communications
⇒
Configure Drivers to call up the
Configure Drivers dialog box.
TIP If you need to reformat the hard drive, you must first
move the evrsi.sys file back to this Master Disk using
this same general procedure; otherwise, the file will
be corrupted. Refer to Removing the RSLinx Software
Activation File on page 4-7.
IMPORTANT
If you are installing ProcessLogix software on a
redundant Server pair, return to the beginning of
Moving the RSLinx Activation File on page 3-10 and
repeat for SERVERB.
Once you have moved the RSLinx activation file on
both SERVERA and SERVERB, continue with the
next section.
IMPORTANT
If you are using Ethernet for your Supervisory
Network, skip to Configuring RSLinx Drivers for
Ethernet Supervisory Network on page 3-18.
