Rockwell Automation 1757-SWKIT4000 ProcessLogix R400.0 Installation and Upgrade Guide - Manual (Page 17)

Publication 1757-IN040B-EN-P - March 2002
Preface 3
Minimum Hardware
Requirements ProcessLogix R400.0 Server Software must be installed on a PC that is
specifically qualified. Use of any other PC variations will render the
standard warranty and support agreement null and void.
Refer to Table P.1: Supported Hardware for ProcessLogix R400.0 on
page P-3 to review the hardware requirements for a new R400.0
ProcessLogix Server. See Table 11.B on page 11-5 and Table 11.C on
page 11-6. for minimum hardware requirements for upgrading an
existing system to R400.0.
Only the hardware listed in Table P.1 below is supported for
ProcessLogix R400.0 Servers. Upgrading from R320.0 requires
new hardware
.
Table P.1: Supported Hardware for ProcessLogix R400.0
Component Description
Base Dell PowerEdge 1400
Processor 1 GHz/133 256K Cache, Pentium III
Mouse Logitec System Mouse
Keyboard Quietkey 104-Key, 6 Pin
System RAM 384MB, DIMM, 133MHz 16x72, 168
CD-ROM 20/48X Black, Compact Disk Drive, IDE
Floppy Drive 1.44MB, F3, NEC P 1400
Hard Drive 18GB 10K, 68P
Tape Drive 20/40G, Tape Backup Unit, Power Vault 100T, DD54
Network Intel Pro 100 Plus, NIC
I/O Expansion 6 PCI
Operating System Microsoft Windows 2000 Server, 5 Client Access Licenses, NTFS,
All hardware component drivers
