Publication 1757-IN040B-EN-P - March 2002

8-32 Supplementary Procedures

Modules for more information about configuring 1757-SRMs in
Control Builder.

3. Once the redundant CPM is created in the Project tab, re-assign

the modules unassigned from the previous non-redundant CPM
to the CEE associated with the new redundant CPM.

Navigate in Knowledge Builder to Control Building
Guide

Control Module Creation

Assigning the CM and IOMs

to the CEE for more information.

4. Load the primary and secondary CPMs and RMs to the

Controllers.

Navigate in Knowledge Builder to Control Building
Guide

Control Strategy Loading

Loading Objects to the CPM

for more information.

This completes the upgrade to a Redundant Chassis Pair.

Installing Knowledge
Builder on a
Non-ProcessLogix System

Knowledge Builder is the software application used to display
ProcessLogix’s documentation. Knowledge Builder (KB) requires
several other software applications and Microsoft components to
function properly. These components are included on the Knowledge
Builder application CD.

Removing Knowledge Builder

Before installing ProcessLogix R400.0 Knowledge Builder, you must
remove and previous versions of Knowledge Builder.

1. Click Start

Settings

Control Panel.

2. Double-click the Add/Remove Programs icon.

3. Click on Knowledge Builder in the list of installed programs and

click Add/Remove.

4. Click Yes to confirm.

IMPORTANT

This release of Knowledge Builder only supports
Windows NT and Windows 2000.
