Renesas H8S/2111B - Manual (Page 70)

Rev. 1.00, 05/04, page 36 of 544
Table 2.7 Bit Manipulation Instructions (2)
Instruction Size * Function
BXOR B C
⊕ ( of ) → C
Logically exclusive-ORs the carry flag with a specified bit in a general
register or memory operand and stores the result in the carry flag.
BIXOR B C
⊕ ∼ ( of ) → C
Logically exclusive-ORs the carry flag with the inverse of a specified
bit in a general register or memory operand and stores the result in
the carry flag.
The bit number is specified by 3-bit immediate data.
BLD B ( of )
→ C
Transfers a specified bit in a general register or memory operand to
the carry flag.
BILD B
∼ ( of ) → C
Transfers the inverse of a specified bit in a general register or
memory operand to the carry flag.
The bit number is specified by 3-bit immediate data.
BST B C
→ ( of )
Transfers the carry flag value to a specified bit in a general register
or memory operand.
BIST B
∼ C → (. of )
Transfers the inverse of the carry flag value to a specified bit in a
general register or memory operand.
The bit number is specified by 3-bit immediate data.
Note: * Size refers to the operand size.
B: Byte
