Rev. 1.00, 05/04, page 293 of 544

Bit Bit

Name

Initial
Value R/W Description

1 IRIC 0 R/(W)*

Clocked synchronous serial format mode:

• At the end of data transfer (rise of the 8th

transmit/receive)

• When a start condition is detected

When the ICDRE or ICDRF flag is set to 1 in any
operating mode:

• When a start condition is detected in transmit mode

(when a start condition is detected in transmit mode

and the ICDRE flag is set to 1)

• When data is transferred among ICDR and buffer

(when data is transferred from ICDRT to ICDRS in

transmit mode and the ICDRE flag is set to 1, or

when data is transferred from ICDRS to ICDRR in

receive mode and the ICDRF flag is set to 1)

[Clearing conditions]

• When 0 is written in IRIC after reading IRIC = 1

Note: * Only 0 can be written, to clear the flag.

When, with the I

2

C bus format selected, IRIC is set to 1 and an interrupt is generated, other flags

must be checked in order to identify the source that set IRIC to 1. Although each source has a
corresponding flag, caution is needed at the end of a transfer.

When the ICDRE or ICDRF flag is set, the IRTR flag may or may not be set. The IRTR flag is not
set at the end of a data transfer up to detection of a retransmission start condition or stop condition
after a slave address (SVA) or general call address match in I

2

C bus format slave mode.

Tables 13.4 and 13.5 show the relationship between the flags and the transfer states.
