Rev. 1.00, 05/04, page 137 of 544
7.13.2 Port E and Port F Output Data Registers (PEODR, PFODR)
PEODR and PFODR store output data for the pins on ports E and F.
Bit Bit Name
Initial
Value R/W
Description
7 PE7ODR 0 R/W
6 PE6ODR 0 R/W
5 PE5ODR 0 R/W
4 PE4ODR 0 R/W
3 PE3ODR 0 R/W
2 PE2ODR 0 R/W
1 PE1ODR 0 R/W
0 PE0ODR 0 R/W
PEODR can always be read or written to, regardless of
the contents of PEDDR.
Bit Bit Name
Initial
Value R/W
Description
7 PF7ODR 0 R/W
6 PF6ODR 0 R/W
5 PF5ODR 0 R/W
4 PF4ODR 0 R/W
3 PF3ODR 0 R/W
2 PF2ODR 0 R/W
1 PF1ODR 0 R/W
0 PF0ODR 0 R/W
PFODR can always be read or written to, regardless of
the contents of PFDDR.
