10.2 Input/Output Pins
Table 10.2 summarizes the input and output pins of the TMR.
Table 10.2 Pin Configuration
Channel Name Symbol I/O Function
Timer output TMO0 Output Output controlled by compare-match
Timer clock input TMCI0 Input External clock input for the counter
TMR_0
Timer reset input TMRI0 Input External reset input for the counter
Timer output TMO1 Output Output controlled by compare-match
Timer clock input TMCI1 Input External clock input for the counter
TMR_1
Timer reset input TMRI1 Input External reset input for the counter
Timer clock/
reset input TMIY/ExTMIY*
(TMCIY/TMRIY) Input External clock input/
external reset input for the counter TMR_Y
Timer output TMOY* Output Output controlled by compare-match
Timer output TMOX/
ExTMOX* Output Output controlled by compare-match TMR_X
Timer clock/
reset input TMIX/ExTMIX*
(TMCIX/TMRIX) Input External clock input/
external reset input for the counter
Timer clock/
reset input TMIB
(TMCIB/TMRIB) Input External clock input/
external reset input for the counter TMR_B
Timer output TMOB Output Output controlled by compare-match
Timer output TMOA Output Output controlled by compare-match TMR_A
Timer clock/
reset input TMIA
(TMCIA/TMRIA) Input External clock input/
external reset input for the counter
Note: * The program development tool (emulator) does not support this pin.
