Rev. 1.00, 05/04, page 97 of 544
Port
Description
Mode 2and Mode 3
I/O Status
Port 6 General I/O port also
functioning as interrupt
input, FRT input/output,
TMR_X and TMR_Y
input/output, and key-
sense interrupt input
P67/TMOX/
KIN7/IRQ7
P66/FTOB/
KIN6/IRQ6
P65/FTID/
KIN5
P64/FTIC/
KIN4
P63/FTIB/
KIN3
P62/FTIA/
KIN2/TMIY
P61/FTOA/
KIN1
P60/FTCI/
KIN0/TMIX
On-chip input pull-
up MOSs
Port 7 General input port also
functioning as A/D
converter analog input
P77
P76
P75/AN5
P74/AN4
P73/AN3
P72/AN2
P71/AN1
P70/AN0
Port 8 General I/O port also
functioning as interrupt
input, SCI_1 input/output,
LPC input/output, and
IIC_1 input/output pins
P86/
IRQ5/SCK1/SCL1
P85/
IRQ4/RxD1
P84/
IRQ3/TxD1
P83/
LPCPD
P82/
CLKRUN
P81/GA20
P80/
PME
Port 9 General I/O port also
functioning as IIC_0
input/output, subclock
input,
φ output, interrupt
input, and A/D converter
external trigger input pins
P97/SDA0
P96/
φ/EXCL
P95
P94
P93
P92/
IRQ0
P91/
IRQ1
P90/
IRQ2/ADTRG
