Rev. 1.00, 05/04, page 74 of 544
• KMIMRA
Bit Bit Name
Initial
Value
R/W Description
7
6
5
4
3
2
1
0
KMIMR15
KMIMR14
KMIMR13
KMIMR12
KMIMR11
KMIMR10
KMIMR9
KMIMR8
1
1
1
1
1
1
1
1
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Keyboard Matrix Interrupt Mask 15 to 8
These bits enable or disable a key-sensing input
interrupt request (KIN15 to KIN8).
0: Enables a key-sensing input interrupt request
1: Disables a key-sensing input interrupt request
• KMIMR
Bit Bit Name
Initial
Value R/W Description
7
6
5
4
3
2
1
0
KMIMR7
KMIMR6
KMIMR5
KMIMR4
KMIMR3
KMIMR2
KMIMR1
KMIMR0
1
0
1
1
1
1
1
1
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Keyboard Matrix Interrupt Mask 7 to 0
These bits enable or disable a key-sensing input
interrupt request (KIN7 to KIN0).
KMIMR6 also performs interrupt request mask control
for pin
IRQ6.
0: Enables a key-sensing input interrupt request
1: Disables a key-sensing input interrupt request
• WUEMRB
Bit Bit Name
Initial
Value R/W Description
7
6
5
4
3
2
1
0
WUEMR7
WUEMR6
WUEMR5
WUEMR4
WUEMR3
WUEMR2
WUEMR1
WUEMR0
1
1
1
1
1
1
1
1
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Wake-Up Event Interrupt Mask 7 to 0
These bits enable or disable a wake-up event input
interrupt request (WUE7 to WUE0).
0: Enables a wake-up event input interrupt request
1: Disables a wake-up event input interrupt request
