Rev. 1.00, 05/04, page 452 of 544

18.11 Programmer

Mode

In programmer mode, the on-chip flash memory can be programmed/erased by a PROM
programmer via a socket adapter, just like for a discrete flash memory. Use a PROM programmer
that supports the Renesas 64-Kbyte flash memory on-chip MCU device*. Figure 18.11 shows a
memory map in programmer mode.

Note: Set the programming voltage of the PROM programmer to 3.3V.

On-chip ROM area

MCU mode

H'000000

Programmer mode

H'00000

H'00FFFF

H'0FFFF

Undefined value output

H'1FFFF

Figure 18.11 Memory Map in Programmer Mode
