• STR2
R/W
Bit Bit Name Initial Value Slave Host Description
7
6
5
4
DBU27
DBU26
DBU25
DBU24
0
0
0
0
R/W
R/W
R/W
R/W
R
R
R
R
Defined by User
The user can use these bits as necessary.
3 C/
D2 0
R R Command/Data
When the host processor writes to an IDR register,
bit 2 of the I/O address is written into this bit to
indicate whether IDR contains data or a command.
0: Contents of data register (IDR) are data
1: Contents of data register (IDR) are a command
2 DBU22 0 R/W R Defined by User
The user can use this bit as necessary.
1 IBF2 0 R R Input Buffer Full
Set to 1 when the host processor writes to IDR. This
bit is an internal interrupt source to the slave
processor (this LSI). IBF is cleared to 0 when the
slave processor reads IDR.
The IBF1 flag setting and clearing conditions are
different when the fast A20 gate is used. For details
see table 15.3.
0: [Clearing condition]
When the slave processor reads IDR
1: [Setting condition]
When the host processor writes to IDR using I/O
write cycle
0 OBF2 0 R/(W)* R Output Buffer Full
Set to 1 when the slave processor (this LSI) writes to
ODR. Cleared to 0 when the host processor reads
ODR.
0: [Clearing condition]
When the host processor reads ODR using I/O
read cycle, or the slave processor writes 0 to the
OBF bit
1: [Setting condition]
When the slave processor writes to ODR
Note: * Only 0 can be written to clear the flag.
