Section 22 Electrical Characteristics
22.1 Absolute Maximum Ratings
Table 22.1 lists the absolute maximum ratings.
Table 22.1 Absolute Maximum Ratings
Item Symbol Value Unit
Power supply voltage V
CC
, V
CL
–0.3 to +4.3 V
I/O buffer power supply voltage V
CC
B –0.3 to +7.0 V
Input voltage (except ports 7, A, P97, P86, P52, P42,
and port G) V
in
–0.3 to V
CC
+0.3 V
Input Voltage (port A) V
in
–0.3 to V
CC
B +0.3 V
Input voltage (P97, P86, P52, P42 and port G) V
in
–0.3 to +7.0 V
Input voltage (port 7) V
in
–0.3 to AV
CC
+ 0.3 V
Reference supply voltage AV
ref
–0.3 to AV
CC
+ 0.3 V
Analog power supply voltage AV
CC
–0.3 to +4.3 V
Analog input voltage V
AN
–0.3 to AV
CC
+0.3 V
Operating temperature T
opr
–20 to +75 °C
Operating temperature (flash memory
programming/erasing) T
opr
–20 to +75 °C
Storage temperature T
stg
–55 to +125 °C
Caution: Permanent damage to the chip may result if absolute maximum ratings are exceeded.
Ensure so that the impressed voltage does not exceed 4.3 V for pins for which the
maximum rating is determined by the voltage on the V
CC
, AV
CC
, and V
CL
pins, or 7.0 V for
pins for which the maximum rating is determined by V
CC
B.
The V
CC
and V
CL
pins must be connected to the Vcc power supply.
