Renesas H8S/2111B User Manual
Page 113
Rev. 1.00, 05/04, page 79 of 544
Vector Address
Origin of
Interrupt
Source
Name
Vector
Number
Normal
Mode
Advanced
Mode
ICR Priority
TMR_0
CMIA0 (Compare match A)
CMIB0 (Compare match A)
OVI0 (Overflow)
Reserved for system use
64
65
66
67
H'0080
H'0082
H'0084
H'0086
H'000100
H'000104
H'000108
H'00010C
ICRB3
High
TMR_1
CMIA1 (Compare match A)
CMIB1 (Compare match B)
OVI1 (Overflow)
Reserved for system use
68
69
70
71
H'0088
H'008A
H'008C
H'008E
H'000110
H'000114
H'000118
H'00011C
ICRB2
TMR_X,
TMR_Y
CMIAY (Compare match A)
CMIBY (Compare match B)
OVIY (Overflow)
ICIX (Input capture X)
72
73
74
75
H'0090
H'0092
H'0094
H'0096
H'000120
H'000124
H'000128
H'00012C
ICRB1
—
Reserved for system use
76
to
83
H'0098
to
H'00A6
H'000130
to
H'00014C
—
SCI_1
ERI1 (Reception error 1)
RXI1 (Reception completion 1)
TXI1 (Transmission data empty 1)
TEI1 (Transmission end 1)
84
85
86
87
H'00A8
H'00AA
H'00AC
H'00AE
H'000150
H'000154
H'000158
H'00015C
ICRC6
—
Reserved for system use
88
to
91
H'00B0
to
H'00B6
H'000160
to
H'00016C
—
IIC_0
IICI0 (1-byte transmission/
reception completion)
Reserved for system use
92
93
H'00B8
H'00BA
H'000170
H'000174
ICRC4
IIC_1
IICI1 (1-byte transmission/
reception completion)
Reserved for system use
94
95
H'00BC
H'00BE
H'000178
H'00017C
ICRC3
Keyboard
buffer
controller
KBIA (Reception completion A)
KBIB (Reception completion B)
KBIC (Reception completion C)
Reserved for system use
96
97
98
99
H'00C0
H'00C2
H'00C4
H'00C6
H'000180
H'000184
H'000188
H'00018C
ICRB0
TMR_A,
TMR_B
CMIAAB (Compare match A)
CMIBAB (Compare match B)
OVIAB (Overflow)
ICIA (Input capture A)
100
101
102
103
H'00C8
H'00CA
H'00CC
H'00CE
H'000190
H'000194
H'000198
H'00019C
ICRC2
—
Reserved for system use
104
to
107
H'00D0
to
H'00D6
H'0001A0
to
H'0001AC
—
LPC ERRI
(Transfer
error)
IBF1 (IDR1 reception completion)
IBF2 (IDR2 reception completion)
IBF3 (IDR3 reception completion)
108
109
110
111
H'00D8
H'00DA
H'00DC
H'00DE
H'0001B0
H'0001B4
H'0001B8
H'0001BC
ICRC1
Low
