Rev. 1.00, 05/04, page 8 of 544
Pin Name
Pin No. Single-Chip Modes Flash Memory
TFP-144 Mode 2, Mode 3 (EXPE = 0) Programmer Mode
121 P30/LAD0 FO0
122 P31/LAD1 FO1
123 P32/LAD2 FO2
124 P33/LAD3 FO3
125 P34/
LFRAME
FO4
126 P35/
LRESET
FO5
127 P36/LCLK FO6
128 P37/SERIRQ FO7
129 P80/
PME
NC
130 P81/GA20 NC
131 P82/
CLKRUN
NC
132 P83/
LPCPD
NC
133 P84/
IRQ3/TxD1
NC
134 P85/
IRQ4/RxD1
NC
135 (N) P86/
IRQ5/SCK1/SCL1
NC
136 P40/TMCI0 NC
137 P41/TMO0 NC
138 (N) P42/TMRI0/SDA1 NC
139 VSS VSS
140 X1 NC
141 X2 NC
142
RESO
NC
143 XTAL XTAL
144 EXTAL EXTAL
Note: The (B) in Pin No. means the VCCB drive and the (N) in Pin No. means the NMOS
push-pull/open-drain drive.
* The program development tool (emulator) does not support this function.
