Rev. 1.00, 05/04, page 511 of 544
Lower Address
Register Name
Register Select Condition
Module Name
H'FFC8
TCR_0
MSTP12 = 0
TMR_0, TMR_1
H'FFC9 TCR_1
H'FFCA TCSR_0
H'FFCB TCSR_1
H'FFCC TCORA_0
H'FFCD TCORA_1
H'FFCE TCORB_0
H'FFCF TCORB_1
H'FFD0 TCNT_0
H'FFD1 TCNT_1
H'FFD3 PWOERA
No
condition
PWM
H'FFD5 PWDPRA
H'FFD6
PWSL
MSTP11 = 0
H'FFD7 PWDR0
to
PWDR7
H'FFD8
ICCR_0
MSTP4 = 0, IICE = 1 in STCR
IIC_0
H'FFD9 ICSR_0
H'FFDE
ICDR_0
ICE = 1 in ICCR0
SARX_0
MSTP4 = 0,
IICE = 1 in
STCR
ICE = 0 in ICCR0
H'FFDF
ICMR_0
ICE = 1 in ICCR0
SAR_0
MSTP4 = 0,
IICE = 1 in
STCR
ICE = 0 in ICCR0
H'FFE0
ADDRAH
MSTP9 = 0
A/D
H'FFE1 ADDRAL
H'FFE2 ADDRBH
H'FFE3 ADDRBL
H'FFE4 ADDRCH
H'FFE5 ADDRCL
H'FFE6 ADDRDH
H'FFE7 ADDRDL
H'FFE8 ADCSR
H'FFE9 ADCR
