Rev. 1.00, 05/04, page 403 of 544

The scope of the initialization in each mode is shown in table 15.6.

Table 15.6 Scope of Initialization in Each Host Interface Mode

Items Initialized

System
Reset LPC

Reset

LPC
Shutdown

LPC transfer cycle sequencer (internal state), LPCBSY and
ABRT flags

Initialized Initialized Initialized

SERIRQ transfer cycle sequencer (internal state), CLKREQ and
IRQBSY flags

Initialized Initialized Initialized

Host interface flags
(IBF1, IBF2, IBF3A, IBF3B, MWMF, C/

D1, C/D2, C/D3, OBF1,

OBF2, OBF3A, OBF3B, SWMF, DBU), GA20 (internal state)

Initialized Initialized Retained

Host interrupt enable bits
(IRQ1E1, IRQ12E1, SMIE2, IRQ6E2,
IRQ9E2 to IRQ11E2, SMIE3B, SMIE3A, IRQ6E3, IRQ9E3 to
IRQ11E3), Q/

C flag, SELREQ bit

Initialized Initialized Retained

LRST flag

Initialized
(0)

Can be
set/cleared

Can be
set/cleared

SDWN flag

Initialized
(0)

Initialized
(0)

Can be
set/cleared

LRSTB bit

Initialized
(0)

HR: 0
SR: 1

0 (can be set)

SDWNB bit

Initialized
(0)

Initialized
(0)

HS: 0
SS: 1

SDWNE bit

Initialized
(0)

Initialized
(0)

HS: 1
SS: 0 or 1

Host interface operation control bits
(LPC3E to LPC1E, FGA20E, LADR3,
IBFIE1 to IBFIE3, PMEE, PMEB, LSMIE, LSMIB, LSCIE, LSCIB,
TWRE, SELSTR3, SELIRQ1, SELSMI, SELIRQ6, SELIRQ9,
SELIRQ10, SELIRQ11, SELIRQ12)

Initialized

Retained

Retained

LRESET signal

Input (port
function

Input Input

LPCPD signal

Input

Input

LAD3 to LAD0,

LFRAME, LCLK, SERIRQ,

CLKRUN signals

Input

Hi-Z

PME, LSMI, LSCI, GA20 signals (when function is selected)

Output

Hi-Z

PME, LSMI, LSCI, GA20 signals (when function is not selected)

Port function

Port function

Note: System reset: Reset by STBY input, RES input, or WDT overflow

LPC reset: Reset by LPC hardware reset (HR) or LPC software reset (SR)

LPC shutdown: Reset by LPC hardware shutdown (HS) or LPC software shutdown (SS)
