Rev. 1.00, 05/04, page 150 of 544
Table 8.2 Internal Clock Selection
PWSL PCSR
PWCKE PWCKS PWCKC PWCKB PWCKA Description
0 — — — — Clock input is disabled (Initial value)
1 0 — — —
φ (system clock) is selected
1 0 0 0
φ/2 is selected
0 0 1
φ/4 is selected
0 1 0
φ/8 is selected
0 1 1
φ/16 is selected
1 0 0
φ/256 is selected*
1 0 1
φ/512 is selected*
1 1 0
φ/1024 is selected*
1 1 1
φ/4096 is selected*
Note: * The program development tool (emulator) does not support this function.
Table 8.3 Resolution, PWM Conversion Period, and Carrier Frequency when
φ = 10 MHz
Internal Clock
Frequency Resolution PWM
Conversion Period
Carrier Frequency
φ 100
ns 25.6
µs 625
kHz
φ/2 200
ns 51.2
µs 312.5
kHz
φ/4 400
ns 102
µs 156.3
kHz
φ/8 800
ns 205
µs 78.1
kHz
φ/16 1.6 µs 410 µs 39.1
kHz
φ/256* 25.6 µs
6.55 ms 2.4 kHz
φ/512* 51.2 µs
13.1 ms 1.2 kHz
φ/1024* 102 µs
26.2 ms 610 kHz
φ/4096* 410 µs
105 ms 152 kHz
Note: * The program development tool (emulator) does not support this function.
