background image

Rev. 1.00, 05/04, page 93 of 544

Section 6 Bus Controller (BSC)

Since this LSI does not have an externally extended function, it does not have an on-chip bus
controller (BSC). Considering the software compatibility with similar products, you must be
careful to set appropriate values to the control registers for the bus controller.

6.1 Register

Descriptions

The bus controller has the following registers.

• Bus control register (BCR)
• Wait state control register (WSCR)

6.1.1

Bus Control Register (BCR)

Bit Bit

Name

Initial
Value R/W Description

7 — 1 R/W

Reserved

The initial value should not be changed.

6

ICIS0

1

R/W

Idle Cycle Insertion

The initial value should not be changed.

5

BRSTRM 0

R/W

Burst ROM Enable

The initial value should not be changed.

4

BRSTS1 1

R/W

Burst Cycle Select 1

The initial value should not be changed.

3

BRSTS0 0

R/W

Burst Cycle Select 0

The initial value should not be changed.

2

 0 R/W

Reserved

The initial value should not be changed.

1

0

IOS1

IOS0

1

1

R/W

R/W

IOS Select 1, 0

The initial value should not be changed.
