Rev. 1.00, 05/04, page 504 of 544
Register
Abbrevia-
tion Reset
High-Speed/
Medium-
Speed Watch Sleep
Sub-
Active Sub-Sleep
Module
Stop
Software
Standby
Hardware
Standby Module
TCR_X Initialized — — — — — — — Initialized TMR_X
TCR_Y Initialized — — — — — — — Initialized TMR_Y
KMIMR Initialized — — — — — — — Initialized INT
TCSR_X Initialized — — — — — — — Initialized TMR_X
TCSR_Y Initialized — — — — — — — Initialized TMR_Y
KMPCR Initialized — — — — — — — Initialized PORT
TICRR Initialized — — — — — — — Initialized TMR_X
TCORA_Y Initialized — — — — — — — Initialized TMR_Y
KMIMRA Initialized — — — — — — — Initialized INT
TICRF Initialized — — — — — — — Initialized TMR_X
TCORB_Y Initialized — — — — — — — Initialized TMR_Y
TCNT_X Initialized — — — — — — — Initialized TMR_X
TCNT_Y Initialized — — — — — — — Initialized TMR_Y
TCORC Initialized — — — — — — — Initialized TMR_X
TISR Initialized — — — — — — — Initialized TMR_Y
TCORA_X Initialized — — — — — — — Initialized
TCORB_X Initialized — — — — — — — Initialized
TMR_X
TCONRI Initialized — — — — — — — Initialized TMR_X
TCONRS Initialized — — — — — — — Initialized TMR_Y
Note: * The program development tool (emulator) does not support these registers.
