Rev. 1.00, 05/04, page 134 of 544

Bit Bit

Name

Initial
Value R/W

Description

7 PD7PIN

Undefined* R

6 PD6PIN

Undefined* R

5 PD5PIN

Undefined* R

4 PD4PIN

Undefined* R

3 PD3PIN

Undefined* R

2 PD2PIN

Undefined* R

1 PD1PIN

Undefined* R

0 PD0PIN

Undefined* R

PDPIN indicates the port D state. PDPIN has the same
address as PDDDR. If a write is performed, the port D
settings will change.

Note: * The initial value is determined according to the PD7 to PD0 pin states.

7.12.4 Port C and Port D Nch-OD Control Register (PCNOCR, PDNOCR)

PCNOCR and PDNOCR specify the output driver type for pins on ports C and D which are
configured as outputs on a bit-by-bit basis.

Bit Bit

Name

Initial
Value

R/W Description

7 PC7NOCR 0 R/W

6 PC6NOCR 0 R/W

5 PC5NOCR 0 R/W

4 PC4NOCR 0 R/W

3 PC3NOCR 0 R/W

2 PC2NOCR 0 R/W

1 PC1NOCR 0 R/W

0 PC0NOCR 0 R/W

0: CMOS (p-channel driver enabled)

1: N-channel open drain (p-channel driver disabled

Bit Bit

Name

Initial
Value R/W Description

7 PD7NOCR 0 R/W

6 PD6NOCR 0 R/W

5 PD5NOCR 0 R/W

4 PD4NOCR 0 R/W

3 PD3NOCR 0 R/W

2 PD2NOCR 0 R/W

1 PD1NOCR 0 R/W

0 PD0NOCR 0 R/W

0: CMOS (p-channel driver enabled)

1: N-channel open drain (p-channel driver disabled)
