Rev. 1.00, 05/04, page 412 of 544
Table 15.9 Host Address Example
Register Host Address when LADR3 = H'A24F Host Address when LADR3 = H'3FD0
IDR3 H'A24A and H'A24E H'3FD0 and H'3FD4
ODR3 H'A24A H'3FD0
STR3 H'A24E H'3FD4
TWR0MW H'A250 H'3FC0
TWR0SW H'A250 H'3FC0
TWR1 H'A251 H'3FC1
TWR2 H'A252 H'3FC2
TWR3 H'A253 H'3FC3
TWR4 H'A254 H'3FC4
TWR5 H'A255 H'3FC5
TWR6 H'A256 H'3FC6
TWR7 H'A257 H'3FC7
TWR8 H'A258 H'3FC8
TWR9 H'A259 H'3FC9
TWR10 H'A25A H'3FCA
TWR11 H'A25B H'3FCB
TWR12 H'A25C H'3FCC
TWR13 H'A25D H'3FCD
TWR14 H'A25E H'3FCE
TWR15 H'A25F H'3FCF
