Rev. 1.00, 05/04, page 510 of 544

Lower Address

Register Name

Register Select Condition

Module Name

H'FFAA PAODR No

condition

PORT

H'FFAB PAPIN

(read)

PADDR

(write)

H'FFAC P1PCR

H'FFAD P2PCR

H'FFAE P3PCR

H'FFB0 P1DDR

H'FFB1 P2DDR

H'FFB2 P1DR

H'FFB3 P2DR

H'FFB4 P3DDR

H'FFB5 P4DDR

H'FFB6 P3DR

H'FFB7 P4DR

H'FFB8 P5DDR

H'FFB9 P6DDR

H'FFBA P5DR

H'FFBB P6DR

H'FFBC PBODR

H'FFBD P8DDR

(write)

PBPIN

(read)

H'FFBE P7PIN

(read)

PBDDR

(write)

H'FFBF P8DR

H'FFC0 P9DDR

H'FFC1 P9DR

H'FFC2 IER

No

condition

INT

H'FFC3 STCR No

condition

SYSTEM

H'FFC4 SYSCR

H'FFC5 MDCR

H'FFC6 BCR

No

condition

BSC

H'FFC7 WSCR
