2.6.1 Table of Instructions Classified by Function
Tables 2.3 to 2.10 summarize the instructions in each functional category. The notation used in
tables 2.3 to 2.10 is defined below.
Table 2.2 Operation Notation
Symbol Description
Rd General register (destination)*
Rs General register (source)*
Rn General register*
ERn General register (32-bit register)
(EAd) Destination operand
(EAs) Source operand
EXR Extended control register
CCR Condition-code register
N N (negative) flag in CCR
Z Z (zero) flag in CCR
V V (overflow) flag in CCR
C C (carry) flag in CCR
PC Program counter
SP Stack pointer
#IMM Immediate data
disp Displacement
+ Addition
– Subtraction
×
Multiplication
÷
Division
∧ Logical
AND
∨ Logical
OR
⊕
Logical exclusive OR
→
Move
∼
NOT (logical complement)
:8/:16/:24/:32 8-, 16-, 24-, or 32-bit length
Note: * General registers include 8-bit registers (R0H to R7H, R0L to R7L), 16-bit registers (R0
to R7, E0 to E7), and 32-bit registers (ER0 to ER7).
