Renesas H8S/2111B - Manual (Page 458)

Rev. 1.00, 05/04, page 424 of 544
H'001
H'000
1
1024
2
1024
1022
1024 1023
1024 FS
Quantization error
Digital output
Ideal A/D conversion
characteristic
Analog
input voltage
H'002
H'003
H'004
H'3FD
H'3FE
H'3FF
Figure 16.5 A/D Conversion Accuracy Definitions
FS
Offset error
Nonlinearity
error
Actual A/D conversion
characteristic
Analog
input voltage
Digital output
Ideal A/D conversion
characteristic
Full-scale error
Figure 16.6 A/D Conversion Accuracy Definitions
