Rev. 1.00, 05/04, page 389 of 544
R/W
Bit Bit Name
Initial
Value Slave Hos
t Description
2 SMIE2 0 R/W — Host SMI Interrupt Enable 2
Enables or disables a host SMI interrupt request when
OBF2 is set by an ODR2 write.
0: Host SMI interrupt request by OBF2 and SMIE2 is
disabled
[Clearing conditions]
• Writing 0 to SMIE2
• LPC hardware reset, LPC software reset
• Clearing OBF2 to 0 (when IEDIR = 0)
1: [When IEDIR = 0]
Host SMI interrupt request by setting OBF2 to 1 is
enabled
[When IEDIR = 1]
Host SMI interrupt is requested
[Setting condition]
• Writing 1 after reading SMIE2 = 0
1 IRQ12E1 0 R/W — Host IRQ12 Interrupt Enable 1
Enables or disables a host IRQ12 interrupt request
when OBF1 is set by an ODR1 write.
0: Host IRQ12 interrupt request by OBF1 and IRQ12E1
is disabled
[Clearing conditions]
• Writing 0 to IRQ12E1
• LPC hardware reset, LPC software reset
• Clearing OBF1 to 0
1: Host IRQ12 interrupt request by setting OBF1 to 1 is
enabled
[Setting condition]
• Writing 1 after reading IRQ12E1 = 0
