Rev. 1.00, 05/04, page 487 of 544
Register Name Abbreviation
Number
of Bits
Address Module
Data
Bus
Width
Number
of
Access
States
I 2 C bus mode register_0 ICMR_0 8 H'FFDF IIC_0 8 2
Slave address register_0 SAR_0 8 H'FFDF IIC_0 8 2
A/D data register AH ADDRAH 8 H'FFE0 A/D
converter 8 2
A/D data register AL ADDRAL 8 H'FFE1 A/D
converter 8 2
A/D data register BH ADDRBH 8 H'FFE2 A/D
converter 8 2
A/D data register BL ADDRBL 8 H'FFE3 A/D
converter 8 2
A/D data register CH ADDRCH 8 H'FFE4 A/D
converter 8 2
A/D data register CL ADDRCL 8 H'FFE5 A/D
converter 8 2
A/D data register DH ADDRDH 8 H'FFE6 A/D
converter 8 2
A/D data register DL ADDRDL 8 H'FFE7 A/D
converter 8 2
A/D control/status register ADCSR 8 H'FFE8 A/D
converter 8 2
A/D control register ADCR 8 H'FFE9 A/D
converter 8 2
Timer control/status register_1 TCSR_1 8 H'FFEA WDT_1 8 2
Timer counter_1 TCNT_1 8 H'FFEA
(write) WDT_1 8 2
Timer counter_1 TCNT_1 8 H'FFEB
(read) WDT_1 8 2
Timer control register_X TCR_X 8 H'FFF0 TMR_X 16 2
Timer control register_Y TCR_Y 8 H'FFF0 TMR_Y 16 2
Keyboard matrix interrupt register 6 KMIMR 8 H'FFF1 INT 8 2
Timer control/status register_X TCSR_X 8 H'FFF1 TMR_X 16 2
Timer control/status register_Y TCSR_Y 8 H'FFF1 TMR_Y 16 2
Pull-up MOS control register KMPCR 8 H'FFF2 PORT 8 2
Input capture register R TICRR 8 H'FFF2 TMR_X 16 2
Time constant register A_Y TCORA_Y 8 H'FFF2 TMR_Y 16 2
Keyboard matrix interrupt register A KMIMRA 8 H'FFF3 INT 8 2
