Rev. 1.00, 05/04, page 512 of 544
Lower Address Register Name Register Select Condition Module Name
H'FFEA TCSR_1 No condition WDT_1
TCNT_1 (write)
H’FFEB TCNT_1 (read)
H'FFF0 TCR_X TMRX/Y = 0 in
TCONRS TMR_X
TCR_Y
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF1 KMIMR MSTP2 = 0, HIE = 0 in SYSCR INT
TCSR_X TMRX/Y = 0 in
TCONRS TMR_X
TCSR_Y
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF2 KMPCR MSTP2 = 0, HIE = 1 in SYSCR PORT
TICRR TMRX/Y = 0 in
TCONRS TMR_X
TCORA_Y
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF3 KMIMRA MSTP2 = 0, HIE = 1 in SYSCR INT
TICRF TMRX/Y = 0 in
TCONRS TMR_X
TCORB_Y
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF4 TCNT_X TMRX/Y = 0 in
TCONRS TMR_X
TCNT_Y
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF5 TCORC TMRX/Y = 0 in
TCONRS TMR_X
TISR
MSTP8 = 0,
HIE = 0 in
SYSCR
TMRX/Y = 1 in
TCONRS TMR_Y
H'FFF6 TCORA_X
H'FFF7 TCORB_X
MSTP8 = 0,
HIE = 0 in
SYSCR TMRX/Y = 0 in
TCONRS
H'FFFC TCONRI MSTP8 = 0, HIE = 0 in SYSCR
TMR_X
H'FFFE TCONRS MSTP8 = 0, HIE = 0 in SYSCR TMR_Y
Note: * The program development tool (emulator) does not support these registers.
