12 usage notes, 1 i/o port status – Renesas H8S/2111B User Manual
Page 512
Rev. 1.00, 05/04, page 478 of 544
20.12 Usage
Notes
20.12.1 I/O
Port
Status
The status of the I/O ports is retained in software standby mode. Therefore, when a high level is
output, the current consumption is not reduced by the amount of current to support the high level
output.
20.12.2 Current
Consumption when Waiting for Oscillation Stabilization
The current consumption increases during oscillation stabilization.
