Rev. 1.00, 05/04, page 33 of 544
Table 2.4 Arithmetic Operations Instructions (2)
Instruction Size * 1 Function
DIVXS B/W Rd
÷ Rs → Rd
Performs signed division on data in two general registers: either 16
bits
÷ 8 bits → 8-bit quotient and 8-bit remainder or 32 bits ÷ 16 bits
→ 16-bit quotient and 16-bit remainder.
CMP B/W/L Rd – Rs, Rd – #IMM
Compares data in a general register with data in another general
register or with immediate data, and sets the CCR bits according to
the result.
NEG B/W/L 0 – Rd
→ Rd
Takes the two's complement (arithmetic complement) of data in a
general register.
EXTU W/L Rd (zero extension)
→ Rd
Extends the lower 8 bits of a 16-bit register to word size, or the lower
16 bits of a 32-bit register to longword size, by padding with zeros on
the left.
EXTS W/L Rd (sign extension)
→ Rd
Extends the lower 8 bits of a 16-bit register to word size, or the lower
16 bits of a 32-bit register to longword size, by extending the sign bit.
TAS* 2 B @ERd – 0, 1
→ ( of @ERd)
Tests memory contents, and sets the most significant bit (bit 7) to 1.
Notes: 1. Size refers to the operand size.
B: Byte
W: Word
L: Longword
2. When using the TAS instruction, use registers ER0, ER1, ER4 and ER5.
