background image

Rev. 1.00, 05/04, page 353 of 544

14.3.2

Keyboard Control Register L (KBCRL)

KBCRL enables the receive counter count and controls the keyboard buffer controller pin output.

Bit Bit

Name

Initial
Value R/W Description

7 KBE

0 R/W

Keyboard

Enable

Enables or disables loading of receive data into KBBR.

0: Loading of receive data into KBBR is disabled

1: Loading of receive data into KBBR is enabled

6

KCLKO

1

R/W

Keyboard Clock Out

Controls KBC clock I/O pin output.

0: KBC clock I/O pin is low

1: KBC clock I/O pin is high

5

KDO

1

R/W

Keyboard Data Out

Controls KBC data I/O pin output.

0: KBC data I/O pin is low

1: KBC data I/O pin is high

4 — 1 — Reserved

This bit is always read as 1 and cannot be modified.

3

2

1

0

RXCR3

RXCR2

RXCR1

RXCR0

0

0

0

0

R

R

R

R

Receive Counter

These bits indicate the received data bit. Their value is
incremented on the fall of KCLK. These bits cannot be
modified.

The receive counter is initialized to 0000 by a reset and
when 0 is written in KBE. Its value returns to 0000 after
a stop bit is received.

0000: —

0001: Start bit

0010: KB0

0011: KB1

0100: KB2

0101: KB3

0110: KB4

0111: KB5

1000: KB6

1001: KB7

1010: Parity bit

1011: —

11- - : —
