Rev. 1.00, 05/04, page 507 of 544
Lower Address Register Name Register Select Condition Module Name
H'FE44 WUEMRB No condition INT
H'FE46 PGODR
H'FE47 PGPIN (read)
PGDDR (write)
H'FE48 PEODR
H'FE49 PFODR
PEPIN (read) H'FE4A
PEDDR (write)
PFPIN (read) H'FE4B
PFDDR (write)
H'FE4C PCODR
H'FE4D PDODR
No condition PORT
PCPIN (read) H'FE4E
PCDDR (write)
PDPIN (read) H'FE4F
PDDDR (write)
H'FED4 ICXR_0
H'FED5 ICXR_1
No condition IIC_0
IIC_1
H'FED8 KBCRH_0
H'FED9 KBCRL_0
H'FEDA KBBR_0
H'FEDC KBCRH_1
H'FEDD KBCRL_1
H'FEDE KBBR_1
H'FEE0 KBCRH_2
H'FEE1 KBCRL_2
H'FEE2 KBBR_2
MSTP2 = 0 Keyboard buffer
controller
H'FEE6 DDCSWR MSTP4 = 0 IIC common
